Microinverters

X1-Micro 4 in 1

1300W/ 1500W / 1600W / 1800W / 2000W / 2200W

The SolaX X1 Micro 4-in-1 integrates 4 MPPT trackers for optimized solar harvesting, supporting high-power modules up to 700W. Enhanced Arc Fault Circuit Interruption (AFCI) ensures safety, while the built-in Wi-Fi/4G module enables real-time monitoring via the SolaX Cloud App. Its plug-and-play design and IP67 rating simplify installation and maintenance in diverse environments.

Watch Video
Data Download

Product Advantage

With a maximum output of 2400VA and up to 19.5A DC input current, the X1-Micro 4 in 1 microinverter delivers industry-leading energy conversion performance. Its advanced 4 MPPT channels ensure superior power optimization across multiple panel orientations.

Safety and Compatibility

Safety Features. Includes a safety protection relay, Reactive Power Control, and Rapid Shutdown Function, ensuring safe operation.

System Compatibility. Supports micro-grid and AC coupling solutions with existing storage systems. Compatible with SolaX Hybrid systems and supports the integration of a single-phase microinverter into a three-phase power grid system.

High Power Output and Multiple MPPT Channels

High Power Output. The X1-Micro 4in1 series microinverters deliver an impressive output power of up to 2200VA, suitable for high-power PV modules.
Multiple MPPT Channels. Equipped with 4 independent MPPT channels, supporting up to 20A DC input current, ensuring compatibility with the latest and previous generation high-power PV modules, allowing substantial input current and output power capabilities.

Built-in High-Reliability Communication Module

Built-in industrial-grade Wi-Fi module for high reliability.
Monitoring and Control. Integrated with the SolaX Cloud, enabling easy monitoring and control through web and mobile apps.

Easy Installation and Maintenance

Compact and Lightweight. Designed for easy installation and maintenance with a small size and lightweight structure.
High Protection Rating. IP67 protection class ensures durability and reliability in various environmental conditions.

Product Parameters

X1-Micro 2400
X1-Micro 2200
X1-Micro 2000
X1-Micro 1800
X1-Micro 1600
X1-Micro 1500
X1-Micro 1300

X1-Micro 2400
- DC INPUT

  Commonly used module power per input 500~750+W
  MPPT voltage range 22 ~ 60 V
  Number of MPP. trackers/strings per MPPT 4 / 1
- AC OUTPUT

  Rated AC output power 2400 VA
- EFFICIENCY

  Peak efficiency 96.50%
  Nominal MPPT efficiency 99.90%
- GENERAL

  Ingress protection rating IP67
  Dimensions (W /H / D) 322x242x48.5 mm
  Weight 6.2 kg
  Cooling Concept Natural cooling
X1-Micro 2200
- DC INPUT

  Commonly used module power per input 450 ~700+W
  MPPT voltage range 22 ~ 60 V
  Number of MPP. trackers/strings per MPPT 4 / 1
- AC OUTPUT

  Rated AC output power 2200 VA
- EFFICIENCY

  Peak efficiency 96.50%
  Nominal MPPT efficiency 99.90%
- GENERAL

  Ingress protection rating IP67
  Dimensions (W /H / D) 322x242x48.5 mm
  Weight 6.2 kg
  Cooling Concept Natural cooling
X1-Micro 2000
- DC INPUT

  Commonly used module power per input 400~670+ W
  MPPT voltage range 22 ~ 60 V
  Number of MPP. trackers/strings per MPPT 4 / 1
- AC OUTPUT

  Rated AC output power 2000 VA
- EFFICIENCY

  Peak efficiency 96.50%
  Nominal MPPT efficiency 99.90%
- GENERAL

  Ingress protection rating IP67
  Dimensions (W /H / D) 322x242x48.5 mm
  Weight 6.2 kg
  Cooling Concept Natural cooling
X1-Micro 1800
- DC INPUT

  Commonly used module power per input 400~600+W
  MPPT voltage range 22 ~ 60 V
  Number of MPP. trackers/strings per MPPT 4 / 1
- AC OUTPUT

  Rated AC output power 1800 VA
- EFFICIENCY

  Peak efficiency 96.50%
  Nominal MPPT efficiency 99.90%
- GENERAL

  Ingress protection rating IP67
  Dimensions (W /H / D) 322x242x48.5 mm
  Weight 6.2 kg
  Cooling Concept Natural cooling
X1-Micro 1600
- DC INPUT

  Commonly used module power per input 360~600+W
  MPPT voltage range 22 ~ 60 V
  Number of MPP. trackers/strings per MPPT 4 / 1
- AC OUTPUT

  Rated AC output power 1600 VA
- EFFICIENCY

  Peak efficiency 96.50%
  Nominal MPPT efficiency 99.90%
- GENERAL

  Ingress protection rating IP67
  Dimensions (W /H / D) 322x242x48.5 mm
  Weight 6.2 kg
  Cooling Concept Natural cooling
X1-Micro 1500
- DC INPUT

  Commonly used module power per input 320~540+ W
  MPPT voltage range 22 ~ 60 V
  Number of MPP. trackers/strings per MPPT 4 / 1
- AC OUTPUT

  Rated AC output power 1500 VA
- EFFICIENCY

  Peak efficiency 96.50%
  Nominal MPPT efficiency 99.90%
- GENERAL

  Ingress protection rating IP67
  Dimensions (W /H / D) 322x242x48.5 mm
  Weight 6.2 kg
  Cooling Concept Natural cooling
X1-Micro 1300
- DC INPUT

  Commonly used module power per input 300~ 505+ W
  MPPT voltage range 22 ~ 60 V
  Number of MPP. trackers/strings per MPPT 4 / 1
- AC OUTPUT

  Rated AC output power 1300 VA
- EFFICIENCY

  Peak efficiency 96.50%
  Nominal MPPT efficiency 99.90%
- GENERAL

  Ingress protection rating IP67
  Dimensions (W /H / D) 322x242x48.5 mm
  Weight 6.2 kg
  Cooling Concept Natural cooling
